OPA206
供应商:
描述: 具有超 ß 输入和 OVP 的低功耗 (240µA)、低噪声 (8nV/√Hz)、精密 e-trim™ 运算放大器
物料参数
| Number of channels: | 1 |
| Total supply voltage (+5 V = 5, ±5 V = 10) (max) (V): | 36 |
| Total supply voltage (+5 V = 5, ±5 V = 10) (min) (V): | 4.5 |
| Vos (offset voltage at 25°C) (max) (mV): | 0.025 |
| GBW (typ) (MHz): | 3.6 |
| Features: | Overvoltage protection, Super Beta, e-Trim™ |
| Slew rate (typ) (V/µs): | 3.2 |
| Rail-to-rail: | Out |
| Offset drift (typ) (µV/°C): | 0.08 |
| Iq per channel (typ) (mA): | 0.22 |
| Vn at 1 kHz (typ) (nV√Hz): | 8 |
| CMRR (typ) (dB): | 140 |
| Rating: | Catalog |
| Operating temperature range (°C): | -40 to 125 |
| Input bias current (max) (pA): | 500 |
| Iout (typ) (A): | 0.025 |
| Architecture: | Bipolar |
| Input common mode headroom (to negative supply) (typ) (V): | 1 |
| Input common mode headroom (to positive supply) (typ) (V): | -1.4 |
| Output swing headroom (to negative supply) (typ) (V): | 0.2 |
| Output swing headroom (to positive supply) (typ) (V): | -0.2 |
| THD + N at 1 kHz (typ) (%): | 0.0004 |
| Number of channels: | 1 |
| Total supply voltage (+5 V = 5, ±5 V = 10) (max) (V): | 36 |
| Total supply voltage (+5 V = 5, ±5 V = 10) (min) (V): | 4.5 |
| Vos (offset voltage at 25°C) (max) (mV): | 0.025 |
| GBW (typ) (MHz): | 3.6 |
| Features: | Overvoltage protection, Super Beta, e-Trim™ |
| Slew rate (typ) (V/µs): | 3.2 |
| Rail-to-rail: | Out |
| Offset drift (typ) (µV/°C): | 0.08 |
| Iq per channel (typ) (mA): | 0.22 |
| Vn at 1 kHz (typ) (nV√Hz): | 8 |
| CMRR (typ) (dB): | 140 |
| Rating: | Catalog |
| Operating temperature range (°C): | -40 to 125 |
| Input bias current (max) (pA): | 500 |
| Iout (typ) (A): | 0.025 |
| Architecture: | Bipolar |
| Input common mode headroom (to negative supply) (typ) (V): | 1 |
| Input common mode headroom (to positive supply) (typ) (V): | -1.4 |
| Output swing headroom (to negative supply) (typ) (V): | 0.2 |
| Output swing headroom (to positive supply) (typ) (V): | -0.2 |
| THD + N at 1 kHz (typ) (%): | 0.0004 |
无库存
